PANELS CURVED TO MEET YOUR REQUIREMENTS

new

new

new

new

Isocurvo® Variabile

Radius tailored to rements


IN EXPANDED POLYSTYRENE (EPS) – MINERAL WOOL OR GLASS WOOL, RADIUS TAILORED TO REQUIREMENTS

ISOCURVO® VARIABILE is a sandwich panel insulated with Expanded Polystyrene (EPS), Mineral Wool (MW) or Glass Wool (GW).
ISOCURVO® VARIABILE is a unique panel, which can be supplied with a bend radius tailored to fit your roof; meaning that, unlike other panels, ISOCURVO® VARIABILE is produced with a radius starting from 3300 mm through to a FLAT panel, offering a solution to the issue of mixed curved/flat roofs.

Internal and external parts in prepainted sheet metal, natural aluminium, prepainted aluminium and aluzinc® in various thicknesses, with intermediate insulation glued on using a press system. The high degree of flexibility in the choice of materials and thicknesses allows us to offer a product that is made to measure for every roof.

Maximum internal dimension 7000 mm. Panel thickness from 40 mm to 200 mm

Lengthwise gasket running along both sides.







Isocurvo®

Variabile

Radius tailored to rements

isocurvo misura raggio.png
isocurvo disegno.png

ISOCURVO® PIANO PANEL COUPLED WITH ISOCURVO® VARIABILE PANEL THE PANELS HAVE THE SAME CHARACTERISTICS


ASSEMBLY INSTRUCTIONS

isocurvo disegno montaggio.png
isocurvo disegno montaggio2.png

CAN BE CUT LENGTHWISE TO DESIRED SIZE. SEE FULL INSTRUCTIONS ON WEBSITE OR IN THE LATTONEDIL TECHNICAL MANUALS.

INSULATION TYPES
